HMI Industrial Android Tablet Capacitive Industrial Touch Screen Computer RoHS

Ask Lasest Price
Brand Name :	LONGYU
Model Number :	LYA070K20C
Certification :	CE RoHS
Price :	TBA
Payment Terms :	T/T, Western Union，Paypal
Supply Ability :	10000PCS/Month
Delivery Time :	7-10 Work Days

Add to Cart

Product Details
Company Profile

HMI Industrial Android Tablet Capacitive Industrial Touch Screen Computer RoHS

Product Description

7 Inch Industrial Touch Screen Computer Full Metal Case Android PC Tablet

LYA070K20C is a high-performance embedded integrated touch screen with the industrial Rockchip RK3568 (quad-core A55 main frequency 2.0 Ghz) CPU as the core. The product features a high-resolution 15.6-inch LED LCD display (resolution 1920 * 1080) and a 10-point capacitive touch screen. It supports USB, Ethernet, DI / DO, RS232, RS485, CAN, WIFI, BT interface, etc. It is suitable for industrial automation control, HMI, small and medium-sized medical analyzer and other industry applications. Built-alone 0.8T NPU can be used for lightweight AI applications.

Product Performance

	parameter	information
System	CPU processor	RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
	Operating System	Android11.0/Ubuntu18.04/Linux 4.19
	Running memory	2GB/4GB
	EMMC	16GB/32GB/64GB/128GB
	GPU	Mali-G52 1-Core-2EE
Display	Size	7.0 Inch
	Resolving power	1024 * 600
	Touch form	Capactive 10 touch
	Luminance	300 cd/ m²
	Angle of view	Full perspective
Material	Material quality	Plastic face frame, metal back cover
	Way to stall	Flat, outer, embedded
	Dimension	192 * 128 * 28mm
	IP protection grade	Industrial grade IP65 dustproof water proof (operating face)
Source	Power interface	3 PIN*2.54mm terminal DC24V provides power supply
Source	Power input	10.6V-13.2V(Recommended value 12V)
Environmental Character istics	Working temperature	-10℃ ~ 60℃
	Storage temperature	-20℃ ~ 70℃
	Operating humidity	5-90 RH%
	Serial port	2 RS232,2 RS232 / RS485 switch; 6-Road TTL serial port (reuse with serial port)
	Audio interface	1-way MIC interface
	Gigabit Ethernet interface	1-Route 10 / 100 Mbps Ethernet port
	HDMI interface	1-Way HDMI output, up to 3840 * 2160 resolution
	TF	1-Route TF card interface
	SIM card	1 Standard drawer-type interface with reserved eSIM interface
	RTC	1 Built-in supercapacitor
	WIFI/BT	2.4G WIFI / BT4.2
	4G interface	Expand the miniPCIE 4G module
	GPIO interface	4-way GPIO, IO direction is input and output configurable, and IO level is 5.0V；
	USB2.0	1 Vertical plug interface USB 2.0,4 horizontal plug interface USB 2.0,1 built-in row pin (USB 2.0)
	USB3.0	1 Vertical USB 3.0 (switch through dial switch)

Safe Use Instruction

Please read this instruction carefully Before using the product.
Please make sure the power is off Before cleaning this product.
Please put it in a safe place to prevent falling during use.
Before connecting the power supply, please Ensure that the correct power supply is used and that the power cord is not damaged or short circuited.
Do not spill liquid on HMI, To avoid burning the internal circuit
Do not disassemble the product. If there is any fault, please contact our technicians.

Company introduction

Wuhan Longyu Intelligent Technology Co., Ltd has a strong R & D, production, sales and management team. Relying on independently developed embedded computer software system and hardware platform technology, we have carefully developed a series of products, the main products include: man-machine interface touch screen, industrial tablet computer all-in-one, ARM industrial motherboard, industrial display, etc. We strive to promote the upgrading of China's manufacturing industry, the research and development of products are widely used in intelligent transportation, automation equipment, terminal self-help equipment, industrial control, electric power, military industry, finance, network security, Marine manufacturing, medical instruments, numerical control, instrumentation, scientific research and other industries, with many well-known enterprises at home and abroad to maintain long-term stable cooperation.
