    Linux IP65 Panel PC TFT 18.5 Inch PC Tablet Touch Screen FCC

    Ask Lasest Price
    Brand Name : LONGYU
    Model Number : DIPA185C-B
    Certification : CE RoHS
    Price : TBA
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 10000PCS/Month
    Delivery Time : 7-10 Work Days
    • Product Details
    • Company Profile

    Linux IP65 Panel PC TFT 18.5 Inch PC Tablet Touch Screen FCC

    Product Description


    18.5 Inch New IP65 Waterproof Industrial Tablet Touch Screens 4*USB3.0 Industrial Panel PC


    Specifications:


    Support I n t e l ® C e l e r o n ™ J 1 9 0 0
    Support I n t e l ® A T o m x 6 4 2 5 E
    Support I n t e l ® C e l e r o n ™ J 6 4 1 2
    Support I n t e l ® C e l e r o n ™ J 6 4 1 3
    Support I n t e l ® C o r e ™ i 3 - 7 0 2 0 U
    Support I n t e l ® C o r e ™ i 5 - 7 3 6 0 U
    Support I n t e l ® C o r e ™ i 7 - 6 5 0 0 U
    Support I n t e l ® C o r e ™ i 7 - 7 5 0 0 U


    ● 4GB DDR4L-3200MT/S high speed memory, up to 16G support


    ● Dual Intel I211AT 10M/100M/1000M adaptive Gigabit network chips


    ● 6 serial ports (up to 2 x RS485), 4*USB3.0, 1*HDMI, 1*DP


    ● WiFi, Bluetooth, 4G, 5G and other wireless configuration optional


    ● Panel mounting hole size (recommended) :453mm x 274mm


    ● Peripheral size IP65:465mm x286mm x 53mm


    ● Installation method: Support 75mm*75mm VESA installation and front embedded installation


    Product Performance:


    System parameter

    CPUIntel®Celeron™ J6413
    frequency1.8~3.0GHz
    Running memorySupport DDR4-2133MT/s, Up to 16GB
    EMMC1 x 3.0" SATA + 1*M.2 2280 M-key

    I/O

    network2 x Intel i211 1000Mbps RJ-45
    MicRealtek ACL662
    USB4 x USB3.0/4 x USB2.0
    Serial port4 x RS-232; 2 x RS-232 / RS-485
    expansion slot1*M.2 2242/50 B-Key support 4G/5G;WIFI
    I/O portDVI-I / 1 x HDMI/2 x GLAN / 4 x USB / Line-out / Mic-in/DC-IN
    Physical characteristicsDimension (W x H x D)

    465mm x286mm x 53mm


    hole size (W x H)

    453mm x 274mm

    Net Weight

    6.67kg

    Operating SystemOperating SystemWindows10, Linux
    PowerInput voltage9-36VDC Supports reverse connection protection
    MaximPower Consumption35W

    Display

    screen18.5" Full HD TFT
    Resolving power

    1920*1080

    Color Dispay16.7MB
    BacklightLED
    Backlight life30000hrs
    Pixel pitch

    0.248*0.248

    Luminance250 cd/cm²
    Contrast1000 : 1
    View angle(L) 89/ (R) 89/ (T) 89 / (B) 89

    Environmental parameter

    Working temperature0 ~ 45° C (32~113°F)
    0 ~ 50° C (32~113°F) ;-20 ~ 60° C (-4 ~ 140°F) (RT)
    Operating Temperature-20 ~ 60° C (-4 ~ 140°F)
    Relative humidity10~95% RH@40°C,non-condensing
    VibrationSSD applied: 1.5 Grms, 5 ~ 500 Hz, 1 hr/axis
    EMCCE/FCC Class B
    waterproofIP65
    Linux IP65 Panel PC TFT 18.5 Inch PC Tablet Touch Screen FCC
